Intura Flat roof window PG-RA A1 100x150 for smoke ventilation

Flat roof window PG-RW A1 100x150cm for smoke extraction

• The Intura PG-RW (for smoke extraction) plastic electric roof window is designed for flat roofs with a slope between 2° and 15°.
• Fitted with double glazing HR++
• This window is equipped with a pre-assembled drive that complies with the EN 12101-2 standard.
• It offers a secure roof connection thanks to a maximum number of pre-assembled parts and comes with matching aluminium clamping strips for mechanical attachment to the roof seal.
• The window is made of weather-resistant plastic hollow chamber profile, which ensures high stability and durability.
• The toughened and fall-through-proof outer pane guarantees maximum safety.
• The window is prepared for connection to a smoke and heat extraction control unit and is suitable for both wet and dry areas.

The Intura PG-RAis also available in the following size (roof opening size):

• 120x120 cm

This window is also available with safety glass:

• Triple safety glass (Ug 0.5)

The window is electrically operated and requires a 24 V DC power supply.

Technical specifications motor:

• Motor opening width: 600 mm
• Temperature resistance: 30 minutes at 300°C
• Certified according to EN 12101-2
• Snow load capacity: SL500

The Intura PG-RAoffers an innovative and reliable solution for the safe removal of smoke and heat, specially designed for a long service life and optimal functionality.
